Equipment

The XT1 NANO ATEX manhole lifting magnet is a high-performance lifting device equipped with 7 neodymium magnets, providing a lifting capacity of up to 210 kg under ideal operating conditions. The magnets are separated and protected by an anti-spark plate, significantly increasing operational safety in explosive environments.

WDE-K50 is a horizontal Woltmann (turbine) type water meter equipped with a pulse output (IWM-PL3 / IWM-PL4), designed for DMA (district metering area) implementation. It provides accurate flow measurement and is fully compatible with flow and pressure loggers. The device can be integrated into existing SCADA systems or used with the logger manufacturer’s data platforms.

Next-Generation Correlating Logger System for Large-Scale Leak Detection EnigmaREACH is Ovarro’s latest-generation correlating acoustic logger system designed for large-scale water network leak detection. It combines mass logger deployment with advanced cloud analytics to automatically identify leak locations — without the need for manual data processing. The system uploads data to the Atrium analytics platform, where correlations are performed automatically and Points of Interest (PoIs) are generated. These can be assigned directly to field technicians via the intuitive mobile app, significantly reducing analyst workload and accelerating DMA investigations. A single 64-logger EnigmaREACH kit can monitor up to 14 km of pipeline (depending on logger spacing), delivering more than double the coverage of traditional lift-and-shift approaches with fewer loggers. EnigmaREACH is built for professional leakage teams who require speed, precision and scalability.

RadarSens is an intrinsically safe radar level monitoring system designed for continuous wastewater and sewer network applications. Certified for use in hazardous Zone 0 environments, the device provides accurate, reliable level measurement without contact with the medium. Using advanced radar sensing technology combined with cellular telemetry (NB-IoT, LTE-M and 2G), RadarSens delivers real-time data transmission and long-term monitoring performance in harsh underground environments. The system is engineered for fast, right-first-time deployment. It can be installed using stainless-steel non-drill brace bars or conventional wall brackets, reducing installation time and eliminating the need for intrusive mounting. An optional laser alignment tool ensures correct positioning during installation. Local configuration is carried out via Bluetooth using the Deployment App (Android/iOS). Installers can verify signal strength, perform sensor reflection checks and upload site data, including photographs, ensuring data quality before leaving site and significantly reducing follow-up visits.

Mikron5 – Advanced Acoustic Leak Detection Precision & Performance Mikron5 is the next-generation acoustic ground microphone, designed for fast and accurate leak detection in buried and pressurised water mains. Using wireless sensor communication, it allows users to quickly pinpoint leaks on-site before excavation. Superior Sound Quality With crystal-clear audio feedback, Mikron5 helps operators distinguish real leaks from background noise, reducing false detections and improving efficiency. GPS Tracking & Data Management Precise GPS mapping records each leak’s exact location and sound file. Excavation and survey data can be uploaded to the Atrium platform for full traceability and documentation. Bluetooth Connectivity Low-energy Bluetooth enables real-time visualisation of dB levels on a tablet, providing mobility and accuracy during fieldwork. Compact, Lightweight & Reliable Small, portable, and durable – Mikron5 is ideal for leakage teams and contractors who need professional-grade performance in any environment. Upgrade your leak detection with Mikron5 – combining advanced technology, clear sound, and seamless data integration for smarter, faster, and more reliable results.

PrimeFlo-T is a hand-held correlation transit-time ultrasonic flowmeter that utilises dual DSP technology. Ultrasonic meter for flow surveys Measures flow on all common pipes Non-invasive sensors Integral data logger Survey application - 24 hour battery life

The next-generation data logger is designed for continuous monitoring of water supply networks, providing precise pressure and flow data logging, secure data transmission, and reliable long-term operation in demanding environmental conditions.

ST20 LISTENING STICK High-performance mechanical acoustic tool for leak detection The ST20 Listening Stick is a robust, high-sensitivity mechanical listening instrument designed for fast and accurate water leak detection on external water distribution networks. It uses pure mechanical amplification through an acoustic resonant chamber, significantly improving leak sound detection on valves, hydrants, service connections, and other pipe fittings. The stick consists of two chromium-plated steel sections that screw together, forming a standard 1.5-meter length. A compact 1-meter version is also available. Leak vibration signals are transmitted through the steel rod to a brass diaphragm inside the resonant cavity, where the noise is mechanically amplified, allowing the operator to clearly distinguish leak noise from ambient system noise—without any electronics. Constructed from chrome-plated mild steel, the ST20 is durable, easy to use, and ideal for both professional leak technicians and users who may find electronic listening devices difficult to interpret. Added benefit A perfect solution for quick valve sound checks — simple, rugged, and practically eternal. An essential instrument for any leak detection technician working on external water mains.

SpillSens is a cost-effective, multi-level digital float sensor designed as an early warning system for sewer blockages and overflows. ATEX Zone 0 certified and built for harsh wastewater environments, it provides continuous level monitoring using digital positioning technology. Installed at a critical height within a chamber, SpillSens constantly monitors its tilt angle to determine whether it is hanging vertically (normal condition) or beginning to float due to rising wastewater levels. When pre-set tilt thresholds are reached, alarm notifications are transmitted via a connected data logger to the SpillGuard online portal. SpillSens supports Incident Prevention Monitoring programmes and helps utilities reduce pollution events, clean-up costs and regulatory penalties.

WDE-K50 (DN100) is a horizontal Woltmann (turbine) type water meter equipped with a pulse output (IWM-PL3 / IWM-PL4), designed for DMA (district metering area) implementation. It provides accurate flow measurement and is fully compatible with flow and pressure loggers. The device can be integrated into existing SCADA systems or used with the logger manufacturer’s data platforms.

DXmic Pro represents the latest generation of digital ground microphones, engineered to precisely locate water leaks with outstanding sound quality and advanced signal analysis. Combining intelligent digital processing with a durable ergonomic design, DXmic Pro helps operators quickly and confidently pinpoint leaks across all pipe materials — from metal to plastic. Equipped with automatic frequency filtering, visual sound analysis, and recording functionality, the system provides a complete and modern solution for professional leak detection.

PrimeProbe is a bi-directional, insertion, full bore, electromagnetic flowmeter for permanent or portable use. Variable length insertion probes Measures a wide range of flow rates Battery life of up to 10 years Operates at up to 25 bar Flexible data logging
